NEW for 2024, the CropAir Self propelled model sprayers are designed for spraying intensively planted crops including ultra narrow vineyards, orchards, berry tunnels, green houses and nurseries.
Featuring a world-leading Fieni fan, brass roll-over nozzle bodies with non-drip diaphragms, remote mount 3-outlet manual controller with manual regulating valve and pressure gauge, the CropAir has been designed to deliver unparalleled coverage, performance and reliability.
Fans Highly efficient Fieni fans designed to generate more air with lower HP. – Fieni 400 mm standard fan fitted with 8 x blades. – Fieni 400 mm Linear Tower fan fitted with 8 x blades.
Spray pumps AR-403 (40 l/min / 40-Bar) pump.
Controls Remote mount 3-outlet manual controller with manual regulating valve and pressure gauge.
Tank 200 litre polyethylene tanks.
Transmission Hydrostatic transmission with foot pedal directional control.
Engine Honda OHV GX-390, 4-stroke petrol 13.5 HP engine. Electric start.
Nozzles – Brass roll-over nozzle bodies fitted with Albuz ATI-80 degree ISO hollow cone nozzles and Albuz ceramic disc and cores. – 400 Standard fan fitted with 5 x brass roll over nozzle bodies per side (10 x nozzles in total). – 400 Linear Tower fan fitted with 6 x brass roll over nozzle bodies per side (12 x nozzles in total).
learn more
Browse the Croplands Horticulture Spray Ranges to learn more about CropAir sprayers.
Magnetic Assist Technology that improves your spray.
Croplands has partnered with MagrowTec to bring magnetic spray assist technology to the Australian and New Zealand markets. MagrowTec is manufactured in state of the art facilities in Ireland. The technology is designed to retrofit on any boomspray regardless of make or model.
MagrowTec technology uses permanent rare earth magnets to expose crop protection fluid to static non-uniform magnetic fields under appropriate flow conditions. This has the impact of affecting the physical properties of the fluid that determine MagrowTec’s characteristic spray droplet formation, droplet dynamics, and droplet adhesion. Critically, MagrowTec technology allows growers to use much smaller droplets without the drift and waste normally associated when using these smaller nozzles.
INCREASED PROFITABILITY
Reduced water rates
Reduced labour costs
Reduced energy costs
Reduced Inputs (Chemical Savings), reduced frequency of spray due to better coverage
INCREASED PRODUCTIVITY
Increased spray windows
Increased spray hours
Increased disease control
Increased yield
BETTER COMPLIANCE
Supports environmental legislation
Supports integrated pest management plans
Better operator health & safety
BETTER ENVIRONMENT
Reduced environmental contamination
Improved water management
Simply Add MagrowTec To Any Sprayer
Existing Croplands customers are reporting better coverage and as a result are maintaining current application rates instead of increasing them.
Proudly partnering with RBR Enterprise to bring you a proven large scale Self-Propelled Sprayer to the market, keeping the ever-changing agricultural industry at the forefront of our designs.
• 11,000L, 9,000L or 7,500L • Dual tank options for Optical Spot Spraying* • Simplicity mechanical drive • Aluminum spray boom available in 48m, 40m & 36m • IVT Transmission option
Proudly distributed and supported by Croplands – the team with the experience to provide unparalleled service and ongoing technical support.
Check out the RBR Review by Farm Machinery Sales
Read more on the RBR Review by Farm Machinery Sales:
Our frames are made from high-grade steel and are fully boxed with secondary reinforcement plates for added strength. We finish them with a polyurea armour coating to ensure superior protection and maximise the life of your equipment.
POWERED BY PERFORMANCE
We’ve installed the best powertrain package combination for maximum gains from your investment. The Cummins 9-liter engine and RDS Allison transmission bring the power, torque, and worry-free operation you need to tackle any field.
STRAIGHTFORWARD SIMPLICITY
The mechanical drive train is a straightforward, no-frills design that offers reliability, lower cost of ownership and unsurpassed performance. The 2-speed transfer case delivers maximum power to both axles, allowing you to attack the adverse field conditions.
ENJOY THE RIDE
Gas shocks and air suspensions provide an all-day comfortable ride for application speeds and protection from the toughest terrain.
See the vortex 390 in action
LEARN MORE
Check out the RBR Enterprise Product Line guide for more information and machine specifications.
Stara Imperador on farm at an introductory price of $697,000 Inc. GST*.
*Terms and conditions apply. New orders must be placed between 20 December 2024 and 28 February 2025 (Promotional Period). Price will apply to the Croplands RRP on all new orders placed during the Promotional Period on the Croplands Stara Imperador. While stocks last. New orders will be delivered to the customer before 30 April 2025 (exclusions for orders for customised units apply).
Introducing the industry’s only mid mount boom sprayer allowing 50/50 weight distribution.
Elevate your operation with the Stara Imperador 4000 series.
Designed and manufactured in Brazil and featuring the world’s only centrally mounted boom, the Imperador 4000 delivers the ultimate in row crop spraying accuracy and efficiency.
Now available in Australia.
Check out Farm Machinery Sales Stara Imperador Review:
The best of spraying technology. Now available in Australia.
Designed by Brazils largest agricultural machinery manufacturer and featuring the world’s only centrally mounted boom, the Imperador 4000 delivers the ultimate in row crop spraying accuracy and efficiency.
• 4000-litre main tank • 36-metre mid-mount boom • 50/50 weight distribution • 3-metre wheel track • 1.6m genuine underframe clearance. 2m option • Four wheel steer standard • Continuous recirculation and tiered booms standard
Proudly distributed and supported by Croplands – the team with the experience to provide unparalleled service and ongoing technical support.
innovation, evolution, and insightful solutions
With Stara’s distinctive look and styling, the Stara Imperador 4000 Series self-propelled sprayers stand out due to their high application precision ensured by central booms.
In addition to technologies such as the Continuous Recirculating System, Nozzle-by-Nozzle Control System, Twin Row Spraying System, and Smart 4-Wheel-Steering System guarantee higher accuracy and significant savings.
Imperador 4000 are equipped with an Up & Down – Hydraulic Lift System, a feature that allows for the highest application height – 3 meters, and the highest ground clearance on the market – 2 meters.
General Features
THE ONLY MID MOUNT BOOM IN THE WORLD
Boom
The Imperador line is the only one in the world with central booms. It ensures more stability during applications and guarantees 58% more of the chemical solution on target*. The total boom length is 30m or 36m.
Engine
Cummins electronic engine 6.7-295 cv with a turbocharger. In addition to providing considerable savings and longer life, the engine emits low pollutants, causes fewer vibrations, and generates lower noise.
Blue Beam System*
This lighting allows wide visibility during nighttime applications.
* Optimal feature.
Continuous Recirculating System*
This exclusive system keeps the chemical solution constantly moving inside the tank and piping system. What it provides: Homogeneity and the exact chemical concentration during applications; Cleaner spraying system, without residues from previous applications; Longer components durability.
*Nozzle-by-Nozzle Control System feature
Optimised Hydraulic System
It identifies the amount of oil required to carry out different operations, especially the spray pump flow. It provides gains of an average of 8 cv. The fuel economy is up to 2.5%.
Mechanical Solution Mixer
In addition to the hydraulic solution agitator, the machine is also equipped with a propeller, which guarantees better solution homogeneity for high-quality applications.
Automatic Section Control
Shuts off the spray nozzle automatically when the Topper 5500 controller identifies an area where the chemical has already been applied, preventing overlap and ensuring savings on chemicals.
*Optional feature.
Stara Smart Transmission System
With a Rexroth hydro-electronic transmission 4×4, information is displayed on Topper 5500, and diagnostics of components is in real-time.
Ground Clearance
The Imperador 4000 has an impressive 1.6m of standard clearance and an option of 2.0m
Rigid Chassis
Greater stability and less vibration result in optimum efficiency and greater comfort.
Chemical Solution Tank
A capacity of 4000L for Imperador 4000. Its exclusive design works as wave breakers.
Clean Water Tank
400L capacity
Weight Distribution
Boom stability is achieved thanks to the machine weight distribution – 50% on the back and 50% on the front.
Technology
Topper 5500 VT
The complete controller for Precision Agriculture, designed and manufactured by Stara. Its touch screen provides efficiency and more interactivity between the machine and the operator.
TD3 Auto Steering
A robust and electro-hydraulic system that ensures shorter response time for operations by using the auto steering. As a result, it reduces failures and overlaps. Additionally, it reduces crop damage and allows for the following machine traffic control for operations.
Conecta
It is a remote access service that connects you, in real-time, to the After-Sales technician in the Stara factory. The connection is established through Topper 5500, which ensures fast and assertive support.
Whenever you need it, just connect it! An agile and at no cost after-sales available straight to your cabin.
Signal Correction*
It adds the best experience in signal correction, ensuring higher precision in crop field operations. It is recommended for auto steering operations that require path following. It delivers the precision of 2.5 cm**, considerably reducing crop damage losses and overlap. As a consequence, it provides a higher operational yield.
* Optimal feature
** There is no need for a base station to repeat the signal. Precision may vary according to the receptor capacity and weather conditions.
Weather Condition Sensor
The Weather Condition Sensors provide temperature and humidity functions, which boost the application efficiency of the Imperador machine.
Additionally, it has as optional features, wind speed and wind direction functions.
Telemetria Stara
The farm in the palm of your hand.
Through this system, you can manage your operations in the crop field in real-time. Any device that has Internet access will provide you with.
Stara Spraying App
The Stara Spraying App allows you to check the savings Imperador can provide your farm with.
Syncro*
Data transmission system via radio. It allows synchronised communication between the machines and provides better planning and faster crop field operations avoiding overlaps and saving fertilisers.
*Optional feature.
Technical Specifications
IMPERADOR 4000
Weight
12120 kg and 12770 kg when equipped with Up & Down – Hydraulic Lift System
Length
8.7 m
Booms
30 or 36 m
Width (folded booms)
3.2 m
Height
4 m and 4.4 m when equipped with Up & Down – Hydraulic Lift System
Distance between axles
4 m
Wheel tread width extending
From 2.9 to 3.5 m
Ground clearance
1.6 and 2 m when equipped with Up & Down – Hydraulic Lift System
Chemical Solution Tank
4000L
Clean water tank
400L
Product incorporator and rinse tank
35L
Trijet nozzle holder
25 cm spacing
Fuel tank
340L
Spray pump
Stainless steel – 803L/min
Tires
380/90 R46
Engine
Cummins electronic engine 6.7 – 295 cv with turbo charger
Controller
Topper 5500 VT
Maximum application height
2.6 to 3 m with Up & Down – Hydraulic Lift System
Agitation system
By solution transfer, hydraulic agitator and mechanical mixer with propeller
Optional features
Up & Down – Hydraulic Lift System Nozzle-by-Nozzle Control System Twin Row Spraying System Smart 4-Wheel-Steering System Blue Beam Rear-view camera Self-supply pump Signal correction
see the stara imperador in action
LEARN MORE
Check out the Stara Imperador buyers guide for more information and machine specifications.
*Terms and conditions apply. New orders must be placed between 20 December 2024 and 28 February 2025 (Promotional Period). Price will apply to the Croplands RRP on all new orders placed during the Promotional Period on the Croplands Stara Imperador. While stocks last. New orders will be delivered to the customer before 30 April 2025 (exclusions for orders for customised units apply).
